| Brand Name: | Wanshid |
| Model Number: | Y83/T-315 |
| MOQ: | 1 set |
| Price: | 9000~10000$ |
| Delivery Time: | 35 days |
| Payment Terms: | L/C,T/T,Western Union |
The 315 ton push-out scrap metal baler is a heavy-duty hydraulic recycling machine designed to compress loose metal scrap into dense, uniform bales. With a nominal pressing force of 3150 kN, it is suitable for medium and large scrap yards, steel mills, foundries, metal processing plants, dismantling centers, and recycling companies.
Compared with a turn-out baler, the push-out discharge design ejects the finished bale horizontally from the compression chamber. This structure is especially suitable for customers who require continuous production, convenient bale handling, and easier integration with grab cranes, conveyors, or other material handling equipment.
The machine can process scrap steel, sheet metal, aluminum scrap, stainless steel offcuts, vehicle body panels, light structural steel, metal stampings, wire, cans, and other recyclable metals. After compression, loose scrap is converted into compact bales that are easier to store, transport, load, and feed into melting furnaces.
Loose metal scrap usually occupies a large amount of storage space and creates difficulties during transportation and furnace charging. Irregular scrap materials can also increase handling time, labor costs, and loading risks.
Direct transportation of uncompressed scrap often results in low truck or container utilization. Lightweight sheet metal and mixed scrap may also be difficult to stack safely.
A 315 ton hydraulic metal baler solves these problems by reducing scrap volume and producing dense bales with consistent dimensions. The compacted material provides better loading efficiency, cleaner storage, and more convenient downstream recycling.
The machine uses multiple hydraulic compression movements to compact scrap inside the large loading chamber. After the bale reaches the required density and size, the hydraulic push-out cylinder ejects it directly from the chamber.
This discharge method avoids manually removing the bale and supports smoother production. The machine can be equipped with PLC control, remote operation, oil cooling, centralized lubrication, and customized feeding systems according to the customer’s working conditions.
The reinforced frame and heavy-duty hydraulic cylinders provide stable compression force, while wear-resistant chamber plates help extend the service life of the equipment.
| Item | Specification |
|---|---|
| Model | 315 Ton Push-Out Metal Baler |
| Nominal Force | 3150 kN |
| Compression Chamber | Approximately 2600 × 1750 × 1200 mm |
| Bale Size | Approximately 450–800 × 500 × 600 mm or 600 × 600 mm |
| Motor Power | 74–88 kW |
| Production Capacity | Approximately 4–5 tons per hour |
| Bale Discharge | Hydraulic Push-Out |
| Control Method | Manual or PLC Automatic Control |
| Hydraulic Pressure | Customized According to Design |
| Cooling System | Optional |
| Remote Control | Optional |
| Voltage | Customized |
| Machine Color | Customized |
Actual production capacity depends on the scrap type, bulk density, feeding efficiency, operator experience, and required bale density.
Powerful 3150 kN compression force
Hydraulic push-out bale discharge
Large loading chamber for bulky scrap
Suitable for continuous recycling operations
High-density and uniform finished bales
Reduced scrap storage and transport volume
Reinforced welded steel structure
Heavy-duty hydraulic cylinders
Manual and automatic operation available
Customized bale size and chamber dimensions
Optional remote control and oil cooling system
Convenient maintenance and spare-parts replacement
This 315 ton push-out metal baler can process a wide range of ferrous and non-ferrous scrap materials, including:
Scrap steel sheets
Steel stamping offcuts
Light structural steel
Vehicle body panels
Metal cans and containers
Aluminum profiles and sheets
Stainless steel scrap
Copper scrap
Steel wire and light rebar
Mixed industrial metal waste
Metal processing leftovers
Demolition scrap
For harder, thicker, or oversized materials, photos and material dimensions should be confirmed before selecting the final machine configuration.
Scrap material is loaded into the compression chamber by grab crane, excavator, conveyor, or manual feeding.
The hydraulic cover and compression cylinders press the loose scrap from different directions. The material is gradually compressed into a compact rectangular bale.
Once the preset pressure or bale size is reached, the chamber door opens and the hydraulic push-out cylinder ejects the finished bale horizontally.
The operator can then continue loading the next batch of scrap. With PLC control, several compression movements can be completed automatically, reducing manual operation and improving production consistency.
The 315 ton push-out scrap metal baler is widely used in:
Large scrap metal recycling yards
Steel production plants
Metal smelting facilities
Automotive dismantling centers
Metal stamping factories
Aluminum processing plants
Industrial waste recycling centers
Port scrap handling facilities
Demolition recycling projects
Foundries and casting plants
The machine is particularly suitable for customers processing several tons of loose metal scrap per hour and requiring efficient bale discharge.
The most suitable baler configuration depends on the scrap material, daily processing volume, feeding method, required bale size, and local power supply.
Customers should provide the following information before quotation:
Main scrap material
Maximum material dimensions
Approximate daily or hourly capacity
Required bale dimensions
Feeding method
Local voltage and frequency
Indoor or outdoor installation
Required automation level
For light sheet metal, a larger chamber may improve feeding efficiency. For harder scrap, the machine structure, hydraulic pressure, and chamber reinforcement should be evaluated carefully.
The machine can be supplied with:
Wireless remote control
PLC automatic control
Hydraulic oil cooling system
Oil heating system for cold regions
Centralized lubrication
Conveyor feeding system
Customized compression chamber
Customized bale dimensions
Additional wear-resistant chamber liners
Spare seals and hydraulic components
Siemens or Schneider electrical components
English or customized control labels
A push-out baler ejects the finished bale horizontally using a hydraulic cylinder. It is more convenient for continuous production and large bale handling. A turn-out baler discharges the bale by rotating or lifting the chamber section.
The typical capacity is approximately 4–5 tons per hour. Actual output depends on the material density, feeding speed, bale size, and operating conditions.
Yes. Bale dimensions and chamber size can be adjusted according to the customer’s scrap type, furnace opening, transport requirements, and handling equipment.
Yes. The machine can compress aluminum scrap, stainless steel offcuts, copper scrap, and other recyclable metals. Different materials may produce different bale densities.
Yes. The baler can be equipped with PLC automatic control, manual control, or a combination of both. Wireless remote control is also available.
An oil cooling system is recommended for hot climates, long working shifts, or continuous production. It helps control hydraulic oil temperature and maintain stable operation.
The finished bale is pushed out horizontally and can be handled by a grab crane, forklift, conveyor, or other suitable equipment according to the site layout.
Yes. The electrical system can be designed for 380 V, 400 V, 415 V, 440 V, 50 Hz, or 60 Hz according to the customer’s local power supply.
